Standard Penetrometer


Standard Penetrometer

Specifications

Usage industrial, Laboratory, Household
Standard IS: 310, 1203, 1448, IP: 60, 49, 50, ASTM: 05, D217, D637
Accessories Penetration cone for empirical estimation of penetration of lubricating Grease, Petroleum jelly e
Weight Approx .: 0.5 kg
Measuring Range: 0 to 10 kgf/cm2
Power Source Electric
Material Steel
Finish Polished

We make available a comprehensive range of Standard Penetrometer highly used to determine grade of bitumen. The penetration tests done by using our high grade Standard Penetrometer efficiently determines the consistency of bitumen for the purpose of grading. We offer our optimum quality Standard Penetrometer at market leading prices. Our Standard Penetrometer is made by using hi-tech machines and latest technology.

Salient Features :
Depth in units 1 /1 0 of millimeter to which a standard needle having a standard weight will penetrate vertically in a duration of five seconds at a temperature of 2StlC determines penetration for gradation.

Specifications :
It consists of a vertical pillar mounted on a base provided with leveling screws. The head, together with diameter plunger rod and cone (or needle) slides on a pillar and can be clamped at any desired height. A rack and pinion and pointer assem bly provides fine adjustment of needle or cone tip to sample. It incorporates a clutch mechanism which makes reading of penetration and subsequent resetting a simple and accurate operation. The dial is graduated in 400 1/10 and the millimeter subdivisions and the needle pointer against figures makes easy reading. Supplied with a bitumen penetration needle, ring weight one each 50 gms. and 100 gms. and two sample containers
