Universal Automatic Compactor


Universal Automatic Compactor

Specifications

Type Soil Compactors
Application Compacting Grained
Weight 10-20kg
Color Natural
Voltage 110V
Power 1-3kw
Driven Type Electric
Warranty 1 Year
Automation Grade Automatic


We are a prominent Manufacturer and Supplier based in India. The company offers Universal Automatic Compactor to the clients. These Universal Automatic Compactors are used to eliminate tedious hand compaction process, which considerably saves time and efforts. With the rammers provided two stroke lengths, available, the compactor can be used for normal compaction/heavy compaction as well as C.B.R. compaction.

  • Better performance
  • Superior quality
  • Simple to use
  • Longer service life


Specifications :
It is a motor driven mechanical compactor useful for soil compaction into 100 mm or 150 mm diameter moulds. Two sets of rammers are provided, one of 2.6 and arranged for 310 mm. drop and other 4.9 kg and arranged for 450 mm fall. For compaction soil into 150 mm diameter moulds, 100 mm face diameter rammers having weights 2.6 kg and 4.89 kg are used. Where as for 100 mm diameter moulds they a re of 50 mm dia. The rammer assembly is provided with a ratchet and pawl arrangement to lift it from the top of the soil layer. When the rammer reaches the required height the pawl release the rammer which falls freely on soil surface. The release mechanism is operated by an arm moving up and down which is connected to a reduction gear coupled to the motor through another arm.
